3-52 BA 901/1101 en – Edition 2.1 * 91101b330.fm
Operation
☞ Turn the starting key to position 1. Ensure that symbol 30 (parking brake indicator light)
on the instrument panel has gone out.
CAUTION:
Do not tow the machine if this symbol illuminates, even if the brake is disabled with the
switch.
☞ Pull the machine slowly
Follow the following instructions under all circumstances:
• Contact your Wacker Neuson dealer if the electrical system is broken down.
• The manufacturer’s warranty shall not apply to accidents or damage caused by
towing.
• No towing away other machines with towing bracket B.
Loading and transporting the machine
Safety instructions
• The transport vehicle must be of adequate size – refer to – see chapter 6 Technical
data on page 6-1 for the machine’s dimensions and weights!
• Remove any mud, snow or ice from the wheels/tracks so that the machine can be
safely driven onto the ramps
• Secure the machine against unintentional movement– see Parking the machine on
page 3-32!
The machine must be loaded and transported properly –
Accident hazard!
☞ It is essential that you read the safety instructions at the beginning of this
chapter and follow any other safety instructions relevant in your country!
☞ Load as follows:
• Secure the transport vehicle with chocks to prevent it from rolling
• Place the access ramps at the smallest possible angle. Ensure that the grade does
not exceed 17° (30 %). Use access ramps with an antiskid surface only.
• Ensure that the loading area is clear and access to it is not obstructed – for example
by superstructures
• Ensure that the access ramps and the wheels/tracks of the loader are free of oil,
grease and ice
• Start the engine of the loader
• Raise the bucket sufficiently so that it will not touch the ramps
• Carefully drive the loader onto the middle of the transport vehicle
• Lower the bucket to the loading area
• Stop the engine
• Apply the parking brake
• Raise the safety bar
