3-50 BA 901/1101 en – Edition 2.1 * 91101b330.fm
Operation
Front window (with cabin option)
Danger!
Careful when opening the front window –
Crushing hazard!
☞ Stay clear (extremities, clothing) of the window channel
☞ Always pull the front window upward with handholds B
☞ Always let levers A lock into place on either side in locks F
Notice!
Raise the safety bar before opening or closing the front window, in order to avoid
any unintentional operation or movement of the machine!
Open the front window as follows:
• Either side of the front window is fitted with a lever
☞ Push levers A down on either side
☞ Pull the front window upward with handholds B
➥ The front window must lock into rails C on either side
☞ Lock with levers A on either side in C
☞ Pull levers A to the rear to do this
☞ Check whether both levers A are actually locked in rails C
Lower the front window as follows:
☞ Push levers A forward on either side
☞ Pull the front window downward with handholds B
Fig. 96:
Fig. 97: Front window
B
C
A
Fig. 96: Upper handholds
Fig. 96: Lower handholds
B
A
C
