WEG CFW700 - Page 222

CFW700 | 217
Appendix B / Anexo B
Appendix B
Anexo B
Inverter
Convertidor
Inversor
Duty Cycle
Régimen de Sobrecarga
Regime de Sobregarga
Output Rated Current
Corriente de Salida Nominal
Corrente Nominal de Saída
(1)
Overload Currents
Corrientes de Sobrecarga
Correntes de Sobrecarga
(Fig. B.1)
Rated Carrier Frequency
Frecuencia de Conmutación
Nominal
Frequência de
Chaveamento Nominal
(2)
Nominal Inverter Surrounding Temperature - Ta
Temperatu ra Nominal Alrededor del Convertidor - Ta
Temperatura Nominal ao Redor do Inversor - Ta
Input Rated Current
Corriente de Entrada Nominal
Corrente Nominal de Entrada
Inverter Power Losses
Pérdidas del
Convertidor
Perdas do Inversor
(3)
IP20 with Minimum
Free Spaces
IP20 con Espacios
Libres Mínimos
IP20 com Espaços
Livres Mínimos
(Fig. B.3 – D ≠ 0)
Side-by-side IP20
IP20 Lado a Lado
(Fig. B.3 – D = 0)
IP21 / Nema1
IP55
Surface Mounting
Montaje en Superficie
Montagem em Superfície
Flange Mounting
Montaje en “Brida”
Montagem em Flange
(4)
(Inom) 1 min 3 s (fsw)
[Arms] [Arms] [Arms] [kHz] [°C/°F] [°C/°F] [°C/°F] [°C/°F] [Arms] [W] [W]
CFW700B33P5T2
ND 33.5 36.9 50.3 5 50 (122) 4 5 (113) 45 (113) 40 (104) 33.5 430 60 HD 28 42 56 5 50 (122) 50 (122) 50 (122) 40 (104) 28 350 50
CFW700C45P0T2
ND 45 49.5 67.5 5 50 (122) 50 (122) 50 (122) 40 (104) 45 590 90 HD 36 54 72 5 50 (122) 50 (122) 50 (122) 40 (104) 36 450 70
CFW700C54P0T2
ND 54 59.4 81 5 50 (122) 50 (122) 50 (122) 40 (104) 54 680 100
HD 45 67.5 90 5 50 (122) 50 (122) 50 (122) 40 (104) 45 540 80
CFW700C70P0T2
ND 70 77 105 5 50 (122) 50 (122) 50 (122) 40 (104) 70 900 140
HD 56 84 112 5 50 (122) 50 (122) 50 (122) 40 (104) 56 680 100
CFW700D86P0T2
ND 86 94.6 129 5 - - 50 (122) 40 (104) 86 970 150
HD 70 105 140 5 - - 50 (122) 40 (104) 70 740 110
CFW700D0105T2
ND 105 116 158 5 - - 50 (122) 40 (104) 105 1200 180
HD 86 129 172 5 - - 50 (122) 40 (104) 86 920 140
CFW700E0142T2
ND 142 156 213 2.5 - - 45 (113) 40 (104) 142 1490 210
HD 115 172 230 5 - - 45 (113) 40 (104) 115 1280 200
CFW700E0180T2
ND 180 198 270 2.5 - - 45 (113) 40 (104) 180 1820 360
HD 142 213 284 5 - - 4 5 (113) 40 (104) 142 1550 350
CFW700E0211T2
ND 211 232 316 2.5 - - 4 5 (113) 40 (104) 211 2040 360
HD 180 270 360 2.5 - - 45 (113) 40 (104) 180 1690 350
CFW700A03P6T4
ND 3.6 4.0 5.4 5 50 (122) 50 (122) 50 (122) - 3.6 130 25
HD 3.6 5.3 7 5 50 (122) 50 (122) 50 (122) - 3.5 110 25
CF W700A05P0T4
ND 5 5.5 7.5 5 50 (122) 50 (122) 50 (122) - 5 140 25 HD 5 7.5 10 5 50 (122) 50 (122) 50 (122) - 5 140 25
