218 | CFW700
Appendix B / Anexo B
Appendix B
Anexo B
Inverter
Convertidor
Inversor
Duty Cycle
Régimen de Sobrecarga
Regime de Sobregarga
Output Rated Current
Corriente de Salida Nominal
Corrente Nominal de Saída
(1)
Overload Currents
Corrientes de Sobrecarga
Correntes de Sobrecarga
(Fig. B.1)
Rated Carrier Frequency
Frecuencia de Conmutación
Nominal
Frequência de
Chaveamento Nominal
(2)
Nominal Inverter Surrounding Temperature - Ta
Temperatu ra Nominal Alrededor del Convertidor - Ta
Temperatura Nominal ao Redor do Inversor - Ta
Input Rated Current
Corriente de Entrada Nominal
Corrente Nominal de Entrada
Inverter Power Losses
Pérdidas del
Convertidor
Perdas do Inversor
(3)
IP20 with Minimum
Free Spaces
IP20 con Espacios
Libres Mínimos
IP20 com Espaços
Livres Mínimos
(Fig. B.3 – D ≠ 0)
Side-by-side IP20
IP20 Lado a Lado
(Fig. B.3 – D = 0)
IP21 / Nema1
IP55
Surface Mounting
Montaje en Superficie
Montagem em Superfície
Flange Mounting
Montaje en “Brida”
Montagem em Flange
(4)
(Inom) 1 min 3 s (fsw)
[Arms] [Arms] [Arms] [kHz] [°C/°F] [°C/°F] [°C/°F] [°C/°F] [Arms] [W] [W]
CF W700A07P0T4
ND 7 7.7 10.5 5 45 (113) 40 (104) 40 (104) - 7 180 30
HD 5.5 8.3 11 5 50 (122) 50 (122) 50 (122) - 5.5 140 25
CF W700A10P0T4
ND 10 11 15 5 45 (113) 45 (113) 4 5 (113) - 10 220 30 HD 10 15 20 5 45 (113) 45 (113) 45 (113) - 10 200 30
CFW700A13P5T4
ND 13.5 14.9 20.3 5 50 (122) 50 (122) 50 (122) - 13.5 280 40
HD 11 16.5 22 5 50 (122) 50 (122) 50 (122) - 11 220 30
CF W700B17P0T4
ND 17 18.7 25.5 5 50 (122) 50 (122) 50 (122) 40 (104) 17 360 50
HD 13.5 20.3 27 5 50 (122) 50 (122) 50 (122) 40 (104) 13.5 270 40
CF W700B24P0T4
ND 24 26.4 36 5 50 (122) 40 (104) 40 (104) 40 (104) 24 490 70 HD 19 28.5 38 5 50 (122) 45 (113) 50 (122) 40 (104) 19 360 50
CF W700B31P0T4
ND 31 34.1 46.5 5 50 (122) 50 (122) 50 (122) 40 (104) 31 560 80
HD 25 37.5 50 5 50 (122) 50 (122) 50 (122) 40 (104) 25 430 60
CFW700C38P0T4
ND 38 41.8 57 5 50 (122) 50 (122) 50 (122) 40 (104) 38 710 110
HD 33 49.5 66 5 50 (122) 50 (122) 50 (122) 40 (104) 33 590 90
CFW700C45P0T4
ND 45 49.5 67.5 5 50 (122) 50 (122) 50 (122) 40 (104) 45 810 120 HD 38 57 76 5 50 (122) 50 (122) 50 (122) 40 (104) 38 650 100
CFW700C58P5T4
ND 58.5 64.4 87.8 5 50 (122) 50 (122) 50 (122) 40 (104) 58.5 1050 160 HD 47 70.5 94 5 50 (122) 50 (122) 50 (122) 40 (104) 47 800 120
CFW700D70P5T4
ND 70.5 77.6 106 5 - - 50 (122) 40 (104) 70.5 1280 190 HD 61 91.5 122 5 - - 50 (122) 40 (104) 61 1050 160
CFW700D88P0T4
ND 88 96.8 132 5 - - 50 (122) 40 (104) 88 1480 220
HD 73 110 146 5 - - 50 (122) 40 (104) 73 1170 180
