Appendix B / Anexo B
Appendix B
Anexo B
Inverter
Convertidor
Inversor
Duty Cycle
Régimen de Sobrecarga
Regime de Sobregarga
Output Rated Current
Corriente de Salida Nominal
Corrente Nominal de Saída
(1)
Overload Currents
Corrientes de Sobrecarga
Correntes de Sobrecarga
(Fig. B.1)
Rated Carrier Frequency
Frecuencia de Conmutación
Nominal
Frequência de
Chaveamento Nominal
(2)
Nominal Inverter Surrounding Temperature - Ta
Temperatu ra Nominal Alrededor del Convertidor - Ta
Temperatura Nominal ao Redor do Inversor - Ta
Input Rated Current
Corriente de Entrada Nominal
Corrente Nominal de Entrada
Inverter Power Losses
Pérdidas del
Convertidor
Perdas do Inversor
(3)
IP20 with Minimum
Free Spaces
IP20 con Espacios
Libres Mínimos
IP20 com Espaços
Livres Mínimos
(Fig. B.3 – D ≠ 0)
Side-by-side IP20
IP20 Lado a Lado
(Fig. B.3 – D = 0)
IP21 / Nema1
IP55
Surface Mounting
Montaje en Superficie
Montagem em
Superfície
Flange Mounting
Montaje en “Brida”
Montagem em Flange
(4)
(Inom) 1 min 3 s (fsw)
[Arms] [Arms] [Arms] [kHz] [°C/°F] [°C/°F] [°C/°F] [°C/°F] [Arms] [W] [W]
CFW700E0105T4
ND 105 115 157 2.5 - - 45 (113) 40 (104) 105 1270 200
HD 88 132 176 2.5 - - 45 (113) 40 (104) 88 1020 190
CF W700E0142T4
ND 142 156 213 2.5 - - 45 (113) 40 (104) 142 1680 210
HD 115 172 230 2.5 - - 45 (113) 40 (104) 115 1290 200
CF W700E0180T4
ND 180 198 270 2.5 - - 45 (113) 40 (104) 180 2050 360
HD 142 213 284 2.5 - - 45 (113) 40 (104) 142 1570 350
CFW700E0211T4
ND 211 232 316 2.5 - - 4 5 (113) 40 (104) 211 2330 360
HD 180 270 360 2.5 - - 45 (113) 40 (104) 180 1940 350
CFW700B02P9T5
ND 2.9 3.2 4.0 5 50 (122) 50 (122) 50 (122) - 2.9 107 59
HD 2.7 4.1 5.4 5 50 (122) 50 (122) 50 (122) - 2.7 103 58
CFW700B04P2T5
ND 4.2 4.6 6.3 5 50 (122) 50 (122) 50 (122) - 4.2 133 62 HD 3.8 5.7 7.6 5 50 (122) 45 (113) 45 (113) - 3.8 125 61
CFW700B07P0T5
ND 7 7.7 10.5 5 50 (122) 50 (122) 50 (122) - 7 188 71
HD 6.5 9.8 13.0 5 50 (122) 50 (122) 50 (122) - 6.5 178 69
CFW700B10P0T5
ND 10 11.0 15.0 5 50 (122) 50 (122) 50 (122) - 10 247 80
HD 9 13.5 18.0 5 50 (122) 50 (122) 50 (122) - 9 227 77
CFW700B12P0T5
ND 12 13.2 18.0 5 50 (122) 50 (122) 50 (122) - 12 287 85 HD 10 15.0 20.0 5 50 (122) 50 (122) 50 (122) - 10 247 80
CF W700B17P0T5
ND 17 18.7 25.5 5 4 5 (113) 45 (113) 45 (113) - 17 385 100 HD 17 25.5 34.0 5 50 (122) 50 (122) 50 (122) - 17 385 100
CFW700C22P0T5
ND 22 24.2 33 5 50 (122) 50 (122) 50 (122) - 22 550 170
HD 19 28.5 38 5 50 (122) 50 (122) 50 (122) - 19 500 120
CFW700C27P0T5
ND 27 29.7 40.5 5 50 (122) 50 (122) 50 (122) - 27 670 215 HD 22 33 44 5 50 (122) 50 (122) 50 (122) - 22 550 270
