CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
118
Range
[Factory Setting]
Parameter Unit Description / Notes
P295
(1)(2)
0 to 20
SSW Nominal [ According to the
Current nominal current
of the Soft-Starter
SSW-06 ]
-
Table 6.31 - Functions of the Relay Outputs
RLxParameterP277 P278 P279
Function
  (RL1) (RL2) (RL3)
Not Used 0 0 0, 4
Running 1 1 1
Full Voltage 2 2 2
External By-pass 3 3 3
FWD/REV-K1 4 - -
FWD/REV-K2 - 4 -
DC-Braking 5 5 5
No Fault 6 6 6
Fault 7 7 7
Fieldbus 8 8 8
Serial 9
9 9
 SoftPLC 10 10 10
No Alarm 11 11 11
Alarm 12 12 12
Breaker Shunt Trip 13 13 13
must be enabled with forward motor direction of rotation. See P231
and the recommended setup at items 3.3 and 3.3.8.
 “FWD/REV-K2” = this operation is similar to the “Running”, but it
must be enabled with reverse motor direction of rotation. See P231
and the recommended setup at items 3.3 and 3.3.8.
 “DC-Braking” = the output will be enabled while the DC-Braking
is active. See P500 and the recommended setup at items 3.3 and
3.3.11.
 “No Fault” = the output is enabled, if the Soft-Starter SSW-06 is
not disabled due to any error.
 “Fault” = the output is enabled, if the Soft-Starter SSW-06 is disa-
bled due to any error.
 “Fieldbus”= it makes it possible for the master of a Fieldbus commu-
nication network to control the digital output. Refer to the Fieldbus
communication manual for more details.
 “Serial”= it makes it possible for the master of a serial commu-
nication network to control the digital output. Refer to the serial
communication manual for more details.
 “SoftPLC”=itallowstheSoftPLCtocontrolthedigitaloutput.Refer
totheWLPSoftwaremanualformoredetails.
 “No Alarm”= the output is enabled, if the Soft-Starter SSW-06 is
not disabled due to any alarm.
 “Alarm”= the output is enabled, if the Soft-Starter SSW-06 is disa-
bled due to any alarm.
 “Breaker Shunt Trip” = Error Group - When one of the following
errors occur: E11, E15, E18, E19, E41, E77, the output is activated.
The tripping of any of these protections may indicate that the SSW-
06 has a short circuit in the power circuit, thyristors or by-pass. They
can be used to open the power isolation circuit breaker (Q1) (Item
3.3).
Table 6.32 - Nominal current conguration
P295
Nominal
Current
P295
Nominal
Current
P295
Nominal
Current
0 10A 8 170A 16 670A
1 16A 9 205A 17 820A
2 23A 10 255A 18 950A
3 30A 11 312A 19 1100A
4 45A 12 365A 20 1400A
5 60A 13 412A 21 1000A
6 85A 14 480A 22 1300A
7 130A 15 604A
