WDR Software User Manual Operation
24-10437-3 Rev. A 3-11
This document contains confidential and proprietary information of Weldex Corporation. 9/10/08
Display Mode Pop-Up Menu
The Display Mode pop-up menu is available from the Quick Access pop-up menu.
PREV SCREEN – Displays previous screen in sequence
NEXT SCREEN – Displays next screen in sequence
1 SCREEN – One screen displayed at a time
4 SCREEN – Four screens displayed at a time
9 SCREEN – Nine screens displayed at a time
16 SCREEN – Sixteen screens displayed at a time. Available only for the 16-channel
DVR.
PIP – Picture-in-Picture display.
Search Pop-Up Menu
The Search pop-up menu is available from the Quick Access pop-up menu.
It can also be accessed by clicking the Search button on the Live Mode taskbar or
the Playback Mode taskbar.
Play Current – Brings up the last frame of the video and the Playback Mode taskbar.
This feature is used to verify recording.
Calendar Search – Opens the Calendar Search screen.
Event Search – Opens the Event Search screen.
Go to First – Launches the oldest recording.
Go to Last – Launches the recording from the beginning of current hour (if
available).
SEARCH MENUS
You can search recorded material using the calendar, list of events, or a specific time
criterion. This section describes in detail all the search options available.
Calendar Search
Use the Calendar Search screen to look for a specific event by date.
To access the Calendar Screen, from the Live Mode or the Playback Mode taskbar
go to Search>Calendar Search.
