Machine Components
Xerox 6204 Wide Format Solution 19
Product Overview
2
Warning
Never touch a labeled area on hot or sharp parts of the machine. You could get burned or incur other injuries.
No. Component Function
1 Feed-in shelf Load original here, face down.
2 Document handler cover Remove this cover to clear a paper jam.
3 Original guide Align the right edge of original with this guide.
4 Control panel This consists of operation buttons, LED indicators and a touch screen.
For more details, refer to the "Control Panel" Section of this chapter.
5 Printer exit port Copies and prints are delivered here face up.
6 Front doors Open these doors to clear a paper jam and load paper media.
7 Small size paper stop Receives/holds small size copies and prints. It can receive up to about
20 sheets in either of the following ways:
z
The paper stop is set upright on the upper part of the front door for
A3 (landscape), A4, ANSI B (landscape), and Arch A bond paper.
z
The paper stop is set upright on the lower part of the front door for
A2 to ANSI D (landscape) bond paper.
8 Catch tray Stores copies and prints.
Bond paper can be stacked after printing up to about 20 sheets.
9 Caster Used for locking the wheels of the machine. Lock these casters after
moving the machine to its installation site.
