Media Types and Loading
Xerox 6204 Wide Format Solution 35
Product Overview
2
5 Pinch the lever at the end of the shaft, and insert
the shaft into the new roll media so that it aligns
with the media size guide.
6 Adjust the roll media’s orientation, and place the
shaft on the shaft guide.
7 Rotate the roll media until the lead edge is
gripped in the roller.
The roll media is automatically loaded, and stops.
Note • If the roll media cannot be loaded properly
because its lead edge is damaged, trim the
lead edge of the media before setting it in
place.
8 Press the cutter button to cut the lead edge of
roll media.
The lead edge of the roll media is cut.
Note • Do not open the cutter cover for the Roll 1 or
Roll 2.
Important • Pressing the cutter button one time cuts the
paper in an 8.3 inch (210 mm) length. When
the cutter button is held down, the roll media is
continuously loaded until the cutter button is
released. The roll media is cut at the point that
the cutter button is released.
9 Remove the piece of paper that was cut.
