Xerox 6204 - Page 48

2 Product Overview
40 Xerox 6204 Wide Format Solution
Product Overview
2
5 Select [Type Weight] for the tray to be set.
6 Select the required type and weight of the
media, and select [Save].
Media Weight
The following are the media types for each media weight (or thickness).
Note • Tracing paper is displayed as "Vellum" on the screen.
7 Select [Save].
Weight
(Thickness)
Media
Type
Name Weight
Light Bond Translucent Bond 18 lb.
Vellum HPH Vellum 20 lb.
Film 4-mil AccuImage Elite -
Ordinary Bond Premium 20 lb.
Performance 20 lb.
Premium Tints 80g/m
2
Premium Fluorescent 80g/m
2
Vellum Premium Tracing 90 90g/m
2
Film Premium Translucent 75 micron 75µm
Heavy Bond Presentation 110g/m
2
Vellum Premium Tracing 112gsm 112g/m
2
Film Premium Translucent 100 micron 100µm
Light
Ordinary
Heavy
Weight
