DocuColor 5000 User Guide
5-6
5. Problem solving
Paper tray jams
CAUTION: Be careful of the Feed Heads and the Feed Rolls.
They can be damaged with rough treatment.
The UI displays an animation showing the tray containing the jam.
1. Open the tray with the jam.
CAUTION: If you hear paper tearing, stop opening the tray. Open
the door of the Transport Module or the SFM Transport Area and
clear the paper from the Transport Module before attempting to
open the tray again.
2. Carefully remove all jammed paper.
3. Use the UI to determine if further jams exist and clear those
areas.
SFM Transport Area Upper Transport Area
Transport Module
Tray 1
Tray 2
Tray 3
Tray 4
