DocuColor 5000 User Guide
7-18
7. Maintenance
Replacing the Fuser Web Assembly
Two messages will display on the UI regarding the Fuser Web.
The first advises you that the web is almost used up and you
should be sure to have a new unit on hand. The second message
displays when the Fuser Web is completely used and you must
replace it. When this message displays, the digital press shuts
down and will not print until the web is replaced.
WARNING: The Fuser area is hot. Be careful when working in this
area to avoid injury.
Use the following procedure to replace the Fuser Web.
1. Open the front doors of the digital press.
2. Grasp handle 4 and move it in the direction of the arrow.
Front Doors
4
