Xerox Docucolor 5000 User Manual

DocuColor 5000 User Guide
7-16
7. Maintenance
Adding Fuser Oil
A message appears on the UI advising you when to add Fuser Oil.
Use the following procedure to replenish the Fuser Oil supply.
1. Open the Right Front Door of the digital press.
2. Place a drop cloth on the floor under the Fuser area. Any oil
spilled on a hard floor will make the floor slippery.
3. To open the Reservoir Cap, grasp the tab at the back of the
cap and pull it forward.
Refer to the following figure for the location of the Fuser Oil
Reservoir Cap.
4. Remove the cap from the bottle of Fuser Oil and replace it
with the Filler Spout Cap.
This cap was provided to you when your digital press was
installed. Contact your Xerox service representative if you
cannot locate the Filler Spout Cap and need another one.

Xerox Docucolor 5000 Specifications

General

Brand	Xerox
Model	Docucolor 5000
Category	Printer
Language	English
