Chapter 2: MicroBlaze Architecture
Performance Counter Command Register
The Performance Counter Command Register (PCCMDR) is used to issue commands to
clear, start, stop, or sample all counters. This register is a write-only register. Issuing a read
request has no effect, and undefined data is read.
Performance Counter Status Register
The Performance Counter Status Register (PCSR) reads the sampled status of the counters.
To read the status for all configured counters, the register should be read repeatedly for
each of the counters. This register is a read-only register. Issuing a write request to the register
does nothing.
Every time the register is read, the selected counter is incremented. By using the
Performance Counter Command Register, the selected counter can be reset to the first
counter again. See
Figure 2-28 and Table 2-45.
X-Ref Target - Figure 2-27
Figure 2-27: Performance Counter Command Register
04
RES
Reserved
31
5
321
SAM
STOP
STACLR
X19763-091117
Table 2-44: Performance Counter Command Register (PCCMDR)
Bits Name Description Reset Value
4Clear
Clear all counters to zero
0
3Start
Start counting configured events for all counters simultaneously
0
2Stop
Stop counting all counters simultaneously
0
1Sample
Sample status and values in all counters simultaneously for reading
0
0 Reset
Reset accessed counter to the first event counter for access using the
Performance Counter Control, Status, Read Data and Write Data
0
X-Ref Target - Figure 2-28
Figure 2-28: Performance Counter Status Register
0
FULL
Reserved
31 21
OF
X19764-082517
