MIDI Data Format
A-39
Appendix MIDI Data Format
KARAOKE 1, 2, 3
1 Delay Time 0~127 0-127 table#7
2 Feedback Level -63~+63 1-127
3 HPF Cutoff Thru~8.0kHz 0-52
4 LPF Cutoff 1.0k~Thru 34-60
5
6
7
8
9
10 Dry/Wet D63>W~D=W~D<W63 1-127 •
11
12
13
14
15
16
CHORUS 1, 2, 3, 4, CELESTE 1, 2, 3, 4
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO PM Depth 0~127 0-127
3 Feedback Level -63~+63 1-127
4 Delay Offset 0~127 0-127 table#2
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W~D=W~D<W63 1-127 •
11
12
13
14
15 Input Mode mono/stereo 0-1
16
FLANGER 1, 2, 3
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Feedback Level -63~+63 1-127
4 Delay Offset 0~63 0-63 table#2
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W~D=W~D<W63 1-127 •
11
12
13
14
LFO Phase Difference -180~+180deg 4-124
15
16
SYMPHONIC
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Delay Offset 0~127 0-127 table#2
4
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W~D=W~D<W63 1-127 •
11
12
13
14
15
16
No Parameter Range Value See
Table
Con-
trol
ROTARY SPEAKER
1 LFO Frequency 0.00~39.7Hz 0-127 table#1 •
2 LFO Depth 0~127 0-127
3
4
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W~D=W~D<W63 1-127
11
12
13
14
15
16
TREMOLO
1 LFO Frequency 0.00~39.7Hz 0-127 table#1 •
2 AM Depth 0~127 0-127
3 PM Depth 0~127 0-127
4
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10
11
12
13
14 -180~+180deg 4-124
15 Input Mode mono/stereo 0-1
16
AUTO PAN
1 LFO Frequency 0.00~39.7Hz 0-127 table#1 •
2 L/R Depth 0~127 0-127
3 F/R Depth 0~127 0-127
4 PAN Direction L<->R, L->R, L<-R,
Lturn, Rturn, L/R 0-5
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10
11
12
13
14
15
16
PHASER1, PHASER2
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Phase Shift 0~127 0-127
4 Feedback Level -63~+63 1-127
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W~D=W~D<W63 1-127 •
11 Stage 3~10 3-10
12 Diffusion Mono/Stereo 0-1
13 LFO Phase Di -180~+180deg 4-124
14
15
16
No Parameter Range Value See
Table
Con-
trol
• : Can be controlled by AC1 (Assignable Controller 1)
No.* : These numbers correspond to the Parameter Suffix numbers in <Table 1-3>
See Table** : Refer to “Effect Data Assign Table”
