Yamaha Disklavier E3 - Page 194

MIDI Data Format
A-40
DISTORTION, OVERDRIVE
1 Drive 0~127 0-127 •
2
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
3 EQ Low Gain -12~+12dB 52-76
4 LPF Cutoff 1.0k~Thru 34-60 table#3
5 Output Level 0~127 0-127
6
7
EQ Mid Frequency 500Hz~10.0kHz 28-54 table#3
8 EQ Mid Gain -12~+12dB 52-76
9 EQ Mid Width 1.0~12.0 10-120
10 Dry/Wet D63>W~D=W~D<W63 1-127
11 Edge (Clip Curve) 0~127 0-127
mild ~sharp
12
13
14
15
16
GUITAR AMP SIMULATOR
1 Drive 0~127 0-127 •
2 AMP Type Off, Stack, Combo, Tube 0-3
3 LPF Cutoff 1.0k~Thru 34-60 table#3
4 Output Level 0~127 0-127
5
6
7
8
9
10 Dry/Wet D63>W~D=W~D<W63 1-127
11 Edge (Clip Curve) 0~127 0-127
mild ~sharp
12
13
14
15
16
3-BAND EQ
1 EQ Low Gain -12~+12dB 52-76
2
EQ Mid Frequency 500Hz~10.0kHz 28-54 table#3
3 EQ Mid Gain -12~+12dB 52-76
4 EQ Mid Width 1.0~12.0 10-120
5 EQ High Gain -12~+12dB 52-76
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
8
9
10
11
12
13
14
15
16
No Parameter Range Value See
Table
Con-
trol
2-BAND EQ
1
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
2 EQ Low Gain -12~+12dB 52-76
3
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
4 EQ High Gain -12~+12dB 52-76
5
6
7
8
9
10
11
EQ Mid Frequency 100Hz~10.0kHz 14-54 table#3
12 EQ Mid Gain -12~+12dB 52-76
13 EQ Mid Width 1.0~12.0 10-120
14
15
16
AUTO WAH
1 LFO Frequency 0.00~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Cutoff Frequency 0~127 0-127 •
4 Resonance 1.0~12.0 10-120
5
6
EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8
EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W~D=W~D<W63 1-127
11
12
13
14
15
16
No Parameter Range Value See
Table
Con-
trol
• : Can be controlled by AC1 (Assignable Controller 1)
No.* : These numbers correspond to the Parameter Suffix numbers in <Table 1-3>
See Table** : Refer to “Effect Data Assign Table”
