Yamaha F100A - Page 168

5-12
E
POWR
TIMING BELT
EXPLODED DIAGRAM
67F-46241-00
265 Nm (27 m
•
kg, 192 ft
•
Ib)
40 mm
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
10 × 45 mm
60 Nm (6.0 m
•
kg, 43 ft
•
Ib)
10 × 35 mm
6 × 30 mm
2
5
3
4
1
7
6
9
10
12
11
16
8
13
14
15
Step Procedure/Part name Q’ty Service points
8 Timing belt 1
9 Driven sprocket bolt 2
10 Washer 2
11 Driven sprocket 2
12 Pin 2
13 Drive sprocket nut 1
14 Drive sprocket 1
15 Pick-up coil rotor 1
16 Woodruff key 1
Reverse the removal steps for installation.
