Yamaha F100A - Page 182

5-19
E
POWR
CYLINDER HEAD COVER
EXPLODED DIAGRAM
17 Nm (1.7 m
•
kg, 12 ft
•
Ib)
2 Nm (0.2 m
•
kg, 1.4 ft
•
Ib)
7 × 48 mm
4 × 8 mm
7
8
5
4
6
2
1
9
10
3
E
M
LT
LT
572572
M
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
6 × 30 mm
4
Step Procedure/Part name Q’ty Service points
7 Screw 8
8 Breather cover 1
9 Bolt 2
10 Fuel pump bracket assy. 1
Reverse the removal steps for installation.
