Yamaha F100A - Page 190

5-23
E
POWR
CYLINDER HEAD ASSY.
EXPLODED DIAGRAM
Å
15 Nm (1.5 m
•
kg, 11 ft
•
Ib)1st
33 Nm (3.3 m
•
kg, 24 ft
•
Ib)2nd
10 × 145 mm
6 × 25 mm
8 × 25 mm
6 × 20 mm
8 × 55 mm
14 Nm (1.4 m
•
kg, 10 ft
•
Ib)1st
28 Nm (2.8 m
•
kg, 20 ft
•
Ib)2nd
E
E
2
1
10
13
11
12
14
7
8
9
4
5
6
3
9
5
1
4
8
0
6
2
3
7
D
C
A
B
E
LT
LT
572572
A
90°3rd
70 Nm (7.0 m
•
kg, 51 ft
•
Ib)*
Step Procedure/Part name Q’ty Service points
7 Bolt 2
8 Thermostat cover 1
9 Thermostat 1
10 Bolt 2
11 Anode cover 2
12 O-ring 2
13 Bolt 2
14 Anode 2
Reverse the removal steps for installation.
