6-25
E
LOWR
SHIMMING
3. Using a thickness gauge at the specified
measurement (M) established above,
check the fit between the shimming
gauge and upper disc of the tool.
4. If the thickness gauge at the M specifi-
cation will not fit, then remove or add
the shim(s) until the thickness gauge
just fits between the shimming gauge
and upper disc of the tool.
NOTE:
Reverse gear shim selection is unneces-
sary.
Thickness gauge:
YU-26900-8
YU-26900-9
Available shim thickness:
0.10, 0.12, 0.15, 0.18, 0.30, 0.40
and 0.50 mm
