Yamaha F100A - Page 428

8-21
–+
ELEC
E
STARTER MOTOR
EXPLODED DIAGRAM
18
17
11
16
14
12
10
9
19
21
20
24
23
22
29
30
28
27
26
25
2
3
31
4
5
6
7
8
32
1
6 × 120 mm
4 × 14 mm
6 × 52 mm
4 × 20 mm
13
15
Step Procedure/Part name Q’ty Service points
25 Pinion gear clip 1
26 Pinion gear stopper 1
27 Pinion gear 1
28 Spring 1
29 Clutch assy. 1
30 Bearing 1
31 Shift lever 1
32 Housing 1
Reverse the disassembly steps for
installation.
