4 - 72
ENG
TRANSMISSION
3. Install:
• primary drive gear bearing
• retainer bolt
4. Install:
• primary drive gear
• circlip
• oil seal
• dowel pins
• gasket
• transmission case cover
(with primary drive gear, bearings)
• transmission case cover bolts
5. Check:
• transmission
Rough movement → Repair.
NOTE:
_
Oil each gear, shaft, and bearing thoroughly.
6. Fill:
• transmission case
Refer to “CHANGING THE TRANSMIS-
SION OIL” in chapter 3.
LT
T
R
.
.
10 Nm (1.0 m · kg, 7.2 ft · lb)
New
New
New
T
R
.
.
13 Nm (1.3 m · kg, 9.4 ft · lb)
