2 - 12
SPEC
ELECTRICAL SPECIFICATIONS
ELECTRICAL SPECIFICATIONS
Item Standard Limit
System voltage
12 V ----
Ignition system
Ignition system type C.D.I. ----
Ignition timing (B.T.D.C.) 5° at 1,500 r/min ----
Advanced type Electrical (Analogue) ----
DC.C.D.I.
Magneto model/manufacturer F5TL/PT. MORIC ----
Pickup coil resistance/color 248 ~ 372 Ω at 20 °C (68 °F)/W/L–W/R ----
C.D.I. unit model/manufacturer 5TL/PT. MORIC ----
Ignition coil
Model/manufacturer 4ST/PT. MORIC ----
Minimum ignition spark gap 6 mm (0.24 in) ----
Primary coil resistance 0.32 ~ 0.48 Ω at 20 °C (68 °F) ----
Secondary coil resistance 5.68 ~ 8.52 kΩ at 20 °C (68 °F) ----
Spark plug cap
Material Resin ----
Resistance 5 kΩ at 20 °C (68 °F) ----
Charging system
Type A.C. magneto ----
Model/manufacturer F5TL/PT. MORIC ----
Standard output 14 V 100 W at 5,000 r/min ----
Lighting coil resistance/color 0.24 ~ 0.36 Ω at 20 °C (68 °F)/Y/R–B ----
Charging coil resistance/color 0.32 ~ 0.48 Ω at 20 °C (68 °F)/W–B ----
Rectifier/regulator
Regulator type Semi conductor-short circuit ----
Model/manufacturer SH656-12/SHINDENGEN ----
No load regulated voltage (DC) 14.1 ~ 14.9 V ----
(AC) 13.0 ~ 14.0 V ----
Rectifier capacity (DC) 8 A ----
(AC) 12 A ----
Battery
Model/manufacturer GM5Z-3B/PT. GS or YB5L-B/PT. YUASA ----
Battery voltage/capacity 12 V/5 Ah ----
Specific gravity 1.280 ----
Headlight type
Krypton bulb ----
