2 - 11
SPEC
CHASSIS SPECIFICATIONS
Front suspension
Suspension type Telescopic fork ----
Front fork type Coil spring/oil damper ----
Front fork travel 90 mm (3.54 in) ----
Spring
Free length 266.7 mm (10.50 in) 261.4 mm
(10.29 in)
Installed length 256.7 mm (10.11 in) ----
Spring rate (K1) 3.90 N/mm (0.40 kgf/mm, 22.27 lb/in) ----
Spring rate (K2) 7.10 N/mm (0.72 kgf/mm, 40.54 lb/in) ----
Spring stroke (K1) 0 ~ 50 mm (0 ~ 1.97 in) ----
Spring stroke (K2) 50 ~ 90 mm (1.97 ~ 3.54 in) ----
Optional spring available No ----
Fork oil
Recommended oil Fork oil 10 W or equivalent ----
Quantity (each front fork leg) 57 cm
3
(2.01 Imp oz, 1.93 US oz) ----
Level (from the top of the inner
tube, with the inner tube fully com-
pressed, and without the fork
spring)
88 mm (3.46 in) ----
Inner tube outer diameter 26 mm (1.02 in) ----
Inner tube bend limit ---- 0.2 mm
(0.008 in)
Rear suspension
Suspension type Unit swing ----
Spring/shock absorber type Coil spring/oil damper ----
Rear shock absorber assembly travel 78 mm (3.07 in) ----
Spring
Free length 249.6 mm (9.83 in) 244.6 mm
(9.63 in)
Installed length 245.6 mm (9.67 in) ----
Spring rate (K1) 28.5 N/mm (2.91 kgf/mm, 162.74 lb/in) ----
Spring rate (K2) 40.0 N/mm (4.08 kgf/mm, 228.40 lb/in) ----
Spring stroke (K1) 0 ~ 50 mm (0 ~1.97 in) ----
Spring stroke (K2) 50 ~ 78 mm (1.97 ~ 3.07 in) ----
Optional spring available No ----
Item Standard Limit
