Yamaha Mio - General Information; Specifications; Periodic Checks and Adjustments

EASF0002
SYMBOLS
The following symbols are not relevant to
every vehicle.
Symbols
1
to
8
indicate the subject of each
chapter.
1
General information
2
Specifications
3
Periodic checks and adjustments
4
Engine
5
Carburetor
6
Chassis
7
Electrical system
8
Troubleshooting
Symbols
9
to
F
indicate the following.
9
Serviceable with engine mounted
0
Filling fluid
A
Lubricant
B
Special tool
C
Tightening torque
D
Wear limit, clearance
E
Engine speed
F
Electrical data
Symbols
G
to
L
in the exploded diagrams
indicate the types of lubricants and lubrication
points.
G
Engine oil
H
Gear oil
I
Molybdenum-disulfide oil
J
Wheel-bearing grease
K
Lithium-soap-based grease
L
Molybdenum-disulfide grease
Symbols
M
to
N
in the exploded diagrams
indicate the following.
M
Apply locking agent (LOCTITE
®
)
N
Replace the part
12
34
56
78
90
AB
CD
EF
GHI
JKL
MN
GEN
INFO
SPEC
CHK
ADJ
ENG
CARB
CHAS
–+
ELEC
TRBL
SHTG
T
R
.
.
E
G
M
B
LS
M
LT
New
