Yamaha Mio - Chassis Tightening Torques

2 - 18
SPEC
TIGHTENING TORQUES
CHASSIS TIGHTENING TORQUES
Part to be tightened Thread size
Tightening torque
Remarks
Nm m · kg ft · lb
Brake master cylinder M6 11 1.1 8.0
Rear brake lever assembly M6 7 0.7 5.1
Front brake lever M6 7 0.7 5.1
Starter lever M6 7 0.7 5.1
Handlebar nut M10 43 4.3 31
Steering ring nut (upper) M25 75 7.5 54 See NOTE
Steering ring nut (lower) M25 30 3.0 22 See NOTE
Engine mounting nut M12 59 5.9 43
Engine mounting rubber damper and engine
bracket
M8 16 1.6 11
Engine bracket and engine assembly M10 32 3.2 23
Rear shock absorber assembly nut M10 32 3.2 23
Rear shock absorber assembly bolt M8 16 1.6 11
Front wheel axle nut M10 40 4.0 29
Rear wheel axle nut M14 105 10.5 75
Disk brake and hub M8 23 2.3 17
LT
Front brake hose holder and front fork outer tube M6 7 0.7 5.1
Front brake hose holder, bracket, and lower
bracket
M6 7 0.7 5.1
Lower front brake hose holder and bracket M6 7 0.7 5.1
Front brake hose holder bracket and lower
bracket
M6 7 0.7 5.1
Speedometer cable guide and lower bracket M6 7 0.7 5.1
Brake caliper upper bolt M12 43 4.3 31
Brake caliper lower bolt M8 23 2.3 17
Brake pad holding bolt M6 10 1.0 7.2
Bleed screw M7 6 0.6 4.3
Brake hose union bolt M10 26 2.6 19
Brake camshaft lever bolt M6 7 0.7 5.1
Front fender M6 7 0.7 5.1
Lower bracket pinch bolt (upper and lower) M10 38 3.8 27
Front fork cap bolt M20 20 2.0 14
Damper rod bolt M10 23 2.3 17
LT
Rearview mirror M10 32 3.2 23
Sidestand bolt M8 26 2.6 19
LS
Sidestand nut M8 16 1.6 11
Rear brake cable holder M6 7 0.7 5.1
Fuel tank and frame M6 7 0.7 5.1
Grab bar and fuel tank M6 8 0.8 5.8
Fuel cock and fuel tank M6 7 0.7 5.1
Sender and fuel tank M5 4 0.4 2.9
Seat M6 7 0.7 5.1
