Yamaha Mio - Page 37

2 - 17
SPEC
TIGHTENING TORQUES
Primary sheave nut Nut M12 1 50 5.0 36
Idle gear plate Bolt M6 2 10 1.0 7.2
Starter wheel gear holder Bolt M6 1 10 1.0 7.2
Crankcase (left and right) Bolt M6 9 10 1.0 7.2
Crankcase stud bolt Bolt M8 4 13 1.3 9.4
Stator coil assembly Bolt M6 3 11 1.1 8.0
Pickup coil bracket Screw M6 2 7 0.7 5.1
Starter motor Bolt M6 2 7 0.7 5.1
Ignition coil Screw M6 2 7 0.7 5.1
Part to be tightened Part name
Thread
size
Q’ty
Tightening torque
Remarks
Nm m · kg ft · lb
