7 - 27
– +
ELEC
CHARGING SYSTEM
EAS00774
TROUBLESHOOTING
Check:
1. fuse
2. battery
3. charging voltage
4. charging coil resistance
5. wiring connections
(of the entire charging system)
NOTE:
_
• Before troubleshooting, remove the following
part(s):
1. seat
2. center cover
3. rear panel
4. right side cover
• Troubleshoot with the following special
tool(s).
EAS00738
EAS00739
The battery is not being charged.
Engine tachometer
90890-03113
Pocket tester
90890-03112
1. Fuse
• Check the fuse for continuity.
Refer to “CHECKING THE FUSE” in chap-
ter 3.
• Is the fuse OK?
YES
NO
Replace the fuse.
2. Battery
• Check the condition of the battery.
Refer to “CHECKING AND CHARGING
THE BATTERY” in chapter 3.
Minimum open-circuit voltage
12.8 V or more at 20 °C (68 °F)
• Is the battery OK?
YES
NO
• Refill battery fluid.
• Clean the battery
terminals.
• Recharge or
replace the battery.
To Next Page
