3 - 35
CHK
ADJ
CHECKING AND LUBRICATING THE CABLES/
LUBRICATING THE LEVERS/
LUBRICATING THE SIDESTAND
EAS00170
CHECKING AND LUBRICATING THE
CABLES
The following procedure applies to all of the
inner and outer cables.
WARNING
_
Damaged outer cable may cause the cable
to corrode and interfere with its movement.
Replace damaged outer cable and inner
cables as soon as possible.
1. Check:
• outer cable
Damage
→
Replace.
2. Check:
• cable operation
Rough movement
→
Lubricate.
NOTE:
_
Hold the cable end upright and pour a few
drops of lubricant into the cable sheath or use
a suitable lubricating device.
Recommended lubricant
Engine oil or a suitable cable
lubricant
EAS00171
LUBRICATING THE LEVERS
Lubricate the pivoting point and metal-to-metal
moving parts of the levers.
Recommended lubricant
Lithium-soap-based grease
EAS00172
LUBRICATING THE SIDESTAND
Lubricate the pivoting point and metal-to-metal
moving parts of the sidestand.
Recommended lubricant
Lithium-soap-based grease
