2 - 19
SPEC
TIGHTENING TORQUES
NOTE:
1. First tighten the ring nut (lower) 30 Nm (3.0 m • kg, 22 ft • lb) by using the torque wrench, then
loosen the ring nut quarter turn.
2. Then, hold the ring nuts (lower) and tighten the ring nut (upper) 75 Nm (7.5 m • kg, 54 ft • lb) by
using the torque wrench.
Seat lock assembly and frame M6 7 0.7 5.1
Rear fender M6 8 0.8 5.8
Rectifier/regulator M6 7 0.7 5.1
Footboard and frame M6 7 0.7 5.1
Leg shield and frame M6 7 0.7 5.1
License plate bracket and license plate stay M6 7 0.7 5.1
License plate stay and frame M6 7 0.7 5.1
Horn bracket and license plate stay M6 7 0.7 5.1
Main switch and frame M6 7 0.7 5.1
Spoke — 30.32.2
Part to be tightened Thread size
Tightening torque
Remarks
Nm m · kg ft · lb
