2 - 10
SPEC
CHASSIS SPECIFICATIONS
Rear tire
Tire type With tube ----
Size 80/90-14M/C 40P ----
Manufacturer/model IRC/NR76 ----
Tire pressure (cold tire)
0 ~ 90 kg 225 kPa (2.25 kgf/cm
2
, 33 psi) ----
Min. tire tread depth ---- 0.8 mm
(0.031 in)
Front brake
Brake type Single-disc brake ----
Operation Right-hand operation ----
Brake lever free play (at lever end) 0 mm (0 in) ----
Brake discs
Diameter × thickness 200 × 3.5 mm (7.87 × 0.14 in) ----
Min. thickness ---- 3.0 mm
(0.12 in)
Max. deflection ---- 0.15 mm
(0.006 in)
Brake pad lining thickness-inner 5.3 mm (0.21 in) 0.8 mm
(0.031 in)
Brake pad lining thickness-outer 5.3 mm (0.21 in) 0.8 mm
(0.031 in)
Master cylinder inside diameter 11 mm (0.43 in) ----
Caliper cylinder inside diameter 33.34 mm (1.31 in) ----
Recommended fluid DOT 4 ----
Rear brake
Brake type Drum brake ----
Drum brake type Leading, trailing ----
Brake lever free play (at lever end) 10 ~ 20 mm (0.39 ~ 0.79 in) ----
Drum inside diameter 130 mm (5.12 in) 131 mm
(5.16 in)
Lining thickness 4.0 mm (0.16 in) 2.0 mm
(0.079 in)
Shoe spring free length
(camshaft side)
52 mm (2.05 in) ----
Shoe spring free length (pivot side) 48 mm (1.89 in) ----
Steering
Steering bearing type Angular bearing ----
Lock to lock angle (left) 47.5° ----
Lock to lock angle (right) 47.5° ----
Item Standard Limit
