SPEC
ELECTRICAL SPECIFICATIONS
Bulbs (voltage/wattage
×
quantity)
Headlight 12 V 32 W/32 W × 1 ----
Tail/brake light 12 V 5 W/21 W × 1 ----
Front turn signal light 12 V 10 W × 2 ----
Rear turn signal light 12 V 10 W × 2 ----
Meter light 12 V 1.7 W × 1 ----
Indicator light
(voltage/wattage
×
quantity)
Turn signal indicator light 12 V 1.7 W × 1 ----
High beam indicator light 12 V 1.7 W × 1 ----
Electric starting system
System type Constant mesh ----
Starter motor
Model/manufacturer 5TL/PT. MORIC ----
Power output 0.25 kW ----
Armature coil resistance 0.032 ~ 0.039 Ω at 20 °C (68 °F) ----
Brushes
Overall length 9.5 mm (0.37 in) 3.5 mm
(0.14 in)
Spring force 5.52 ~ 8.28 N
(563 ~ 844 gf, 19.87 ~ 29.80 oz)
----
Commutator diameter 22 mm (0.87 in) 21 mm
(0.83 in)
Mica undercut 1.5 mm (0.06 in) ----
Starter relay
Model/manufacturer 5TN/OMRON ----
Amperage 50 A ----
Coil resistance 54 ~ 66 Ω at 20 °C (68 °F) ----
Horn
Horn type Plane ----
Model/manufacturer × quantity 3WE/PT. MORIC × 1 ----
Max. amperage 1.5 A ----
Performance 95 ~ 105 dB/2 m ----
Coil resistance 4.30 ~ 4.80 Ω ----
Turn signal relay
Relay type Condenser ----
Model/manufacturer FR22-091/PT. MITSUBA ----
Self-cancelling device built-in No ----
Turn signal blinking frequency 75 ~ 95 cycles/min. ----
Wattage 10 W × 2 + 3.4 W ----
Fuel gauge
Model/manufacturer 5TL/NIPPON SEIKI ----
Sender unit resistance- full 4 ~ 10 Ω at 20 °C (68 °F) ----
Sender unit resistance- empty 90 ~ 100 Ω at 20 °C (68 °F) ----
