7 - 19
– +
ELEC
ELECTRIC STARTING SYSTEM
EAS00749
EAS00764
EAS00766
5. Main switch
• Check the main switch for continuity.
Refer to “CHECKING THE SWITCHES”.
• Is the main switch OK?
YES
NO
Replace the main
switch.
6. Start switch
• Check the start switch for continuity.
Refer to “CHECKING THE SWITCHES”.
• Is the start switch OK?
YES
NO
Replace the right
handlebar switch.
7. Front brake light switch
• Check the front brake light switch for conti-
nuity.
Refer to “CHECKING THE SWITCHES”.
• Is the front brake light switch OK?
YES
NO
Replace the front
brake light switch.
8. Rear brake light switch
• Check the rear brake light switch for conti-
nuity.
Refer to “CHECKING THE SWITCHES”.
• Is the rear brake light switch OK?
YES
NO
Replace the rear
brake light switch.
9. Wiring
• Check the entire starting system’s wiring.
Refer to “CIRCUIT DIAGRAM”.
• Is the starting system’s wiring properly
connected and without defects?
YES
NO
The starting system
circuit is OK.
Properly connect or
repair the starting
system’s wiring.
