Yamaha Mio - Page 59

3 - 5
CHK
ADJ
COVERS
3. Remove:
• bottom cowling 1
1
1
4. Remove:
• front bottom cowling 1
1
5. Remove:
• battery breather hose 2 1
•
footboard
2
1
2
6. Remove:
• main switch cover 1
• leg shield 2
NOTE:
Remove the main switch cover by turning it in
the direction of the arrow shown.
2
1
