2 - 13
SPEC
MAINTENANCE SPECIFICATIONS
Front disc brake:
Disc brake type Single
Disc outside diameter
×
thickness 267
×
4
<Limit> <3.5 mm>
Brake pad lining thickness 5.3 mm
<Limit> <0.8 mm>
Master cylinder inside diameter 11 mm
Caliper cylinder inside diameter 26.99 mm
22.22 mm
Recommended fluid DOT 3 or 4
Rear drum brake:
Type Leading and trailing
Drum inside diameter 130 mm
<Limit> <131 mm>
Lining thickness 4 mm
<Limit> <1 mm>
Shoe spring free length 50.5 mm
Brake lever and brake pedal:
Brake lever free play 2 ~ 5 mm
Brake pedal free play 20 ~ 30 mm
Clutch lever:
Clutch lever free play 10 ~ 15 mm
Item SX-4
