OTE:
1. First, tighten the ring nut approximately 48 Nm (4.8 m • kg) by using the torque wrench, then
loosen the ring nut one turn.
2. Retighten the ring nut 18 Nm (1.8 m • kg).
Part to be tightened Thread size
Tightening
torque
Remarks
Nm m·kg
Handle crown and inner tube M8
×
1.25 23 2.3
Handle crown and steering stem M22
×
1.0 110 11.0
Steering stem and ring nut – 18 1.8 See NOTE
Handle crown and upper holder M8
×
1.25 19 1.9
Master cylinder M6
×
1.0 7 0.7
Engine stay and engine M10
×
1.25 58 5.8
Engine stay and frame M8
×
1.25 30 3.0
Engine mounting (rear-lower) and frame M10
×
1.25 79 7.9
Engine mounting (rear-upper) and frame M10
×
1.25 58 5.8
Engine mounting (front) and frame M10
×
1.25 58 5.8
Tension bar and swingarm M8
×
1.25 16 1.6
Kick starter and frame M10
×
1.25 52 5.2
Front wheel axle M14
×
1.5 58 5.8
Front brake disc M6
×
1.0 23 2.3
Front brake caliper M10
×
1.25 30 3.0
Brake hose union bolt M10
×
1.25 26 2.6
Brake caliper bleed screw M7
×
1.0 6 0.6
Rear wheel axle M14
×
1.5 85 8.5
Sprocket and wheel hub M8
×
1.25 30 3.0
Tension bar and rear brake shoe plate M8
×
1.25 16 1.6
Brake lever camshaft M6
×
1.0 10 1.0
Fuel sender and fuel tank M5
×
0.8 4 0.4
Footrest and footrest bracket M8
×
1.25 30 3.0
Footrest bracket and brake pedal M10
×
1.25 30 3.0
Footrest bracket and frame M8
×
1.25 30 3.0
Rear footrest bracket and frame M8
×
1.25 30 3.0
Pivot shaft M12
×
1.25 59 5.9
Rear shock absorber (upper) M12
×
1.25 59 5.9
Rear shock absorber (lower) M12
×
1.25 59 5.9
Relay arm and frame M12
×
1.25 59 5.9
Relay arm and connecting rod M12
×
1.25 59 5.9
Connecting rod and frame M12
×
1.25 59 5.9
Chain case and swingarm M6
×
1.0 7 0.7
Chain guide and swingarm M6
×
1.0 7 0.7
