VALVE CLEARANCE ADJUSTMENT/
IDLING SPEED ADJUSTMENT
●
Measure the valve clearance by using a
feeler gauge.
Out of specification
→
Adjust clearance.
*****************************************************
5.Adjust:
●
Valve clearance
*****************************************************
Adjustment steps:
●
Loosen the locknut
1
.
●
Turn the adjuster
2
in or out with the tappet
adjusting tool
3
until specified clearance is
obtained.
●
Hold the adjuster to prevent it from moving
and tighten the locknut.
●
Measure the vale clearance.
●
If the clearance is incorrect, repeat above
steps until specified clearance is obtained.
*****************************************************
6.Install:
●
O-ring
●
Tappet cover (intake side)
Turning in
Valve clearance is
decreased.
Turning out
Valve clearance is
increased.
Tappet adjusting tool:
90890-01311
T
R
.
.
14 Nm (1.4 m • kg)
T
R
.
.
18 Nm (1.8 m • kg)
IDLING SPEED ADJUSTMENT
1.Start the engine and let it warm up for sev-
eral minutes.
2.Attach:
●
Engine tachometer to the spark plug lead.
Engine tachometer:
90890-03113
To Next Page
