Yamaha SRCD User Manual

10-5
10
OTHER OPERATIONS
10-2 DIO Monitor Display
10-2 DIO Monitor Display
Data indicating whether the I/O signals are on or off can be displayed on the screen. The operation
procedure is explained below.
10-2-1 Display from the monitor menu
1) On the initial screen, press
F4
(MON).
[MENU]
select menu
1EDIT2OPRT3SYS 4MON
DI 10000000 00000000
10000000
DO 00000000 10100000
XO:1 YO:1 XS:1 YS:1
[MENU]
select menu
1EDIT2OPRT3SYS 4MON
2) The ON/OFF status of I/O signals is displayed.
For information about what the display shows,
refer to "4-3-4 DIO monitor screen".
3) To return to the initial screen, press
ESC
.
