MENU
Drive Mode
Drive can be operated and its
status can be displayed.
Quick Programming Mode
Minimum parameters required
for operation can be monitored
or set.
Advanced Programming Mode
All parameters can be moni-
tored or set.
Verify Mode
Parameters changed from the
default settings can be moni-
tored or set.
Autotuning Mode
Automatically sets motor
parameters if autotuning data
(from motor nameplate) is
input for open-loop vector con-
trol or to measure the line-to-
line resistance for V/f control.
No. Function
Display
U1 Status Monitor Parameters
Monitor
U2 Fault Trace
Fault Trace
U3 Fault History
Fault History
A1 Initialize Mode
Initialization
A2 User-specified Setting Mode
User
Parameters
b1 Operation Mode Selections
Sequence
b2 DC Injection Braking
DC Braking
b3 Speed Search
Speed Search
b4 Timer Function
Delay Timers
b5 PID Control
PID Control
b6 Dwell Functions
PID Control
b7 Droop Control
Droop Control
b8 Energy Saving
Energy
Saving
b9 Zero Servo
Zero Servo
C1 Acceleration/Deceleration
Accel/Decel
C2 S-curve Acceleration/Deceleration
S-Curve Accel
C3 Motor Slip Compensation
Motor-Slip
Comp
C4 Torque Compensation
Torque Comp
C5 Speed Control (ASR)
ASR Tuning
C6 Carrier Frequency
Carrier Freq
d1 Preset Reference
Preset
Reference
d2 Reference Limits
Reference
Limits
d3 Jump Frequencies
Jump
Frequencies
d4 Reference Frequency Hold
Sequence
d5 Torque Control
Tor q u e C on tr ol
d6 Field Control
Field-
weakening
E1 V/f Pattern
V/f Pattern
E2 Motor Setup
Motor Setup
E3 Motor 2 V/f Pattern
V/f Pattern 2
E4 Motor 2 Setup
Motor Setup 2
F1 PG Option Setup
PG Option
Setup
F2 Analog Reference Card
AI-14 Setup
F3 Digital Reference Card
DI-08, 16 Setup
F4 Analog Monitor Cards
AO-08, 12
Setup
F5 Digital Output Card
DO-02,08
Setup
F6 Communications Option Card
CP-916 Setup
H1 Multi-function Contact Inputs
Digital Inputs
H2 Multi-function Contact Outputs
Digital
Outputs
H3 Analog Inputs
Analog Inputs
H4 Multi-function Analog Outputs
Analog
Outputs
H5 MODBUS Communications
Serial Com
Setup
H6 Pulse Train
Pulse I/O Setup
L1 Motor Overload
Motor
Overload
L2 Power Loss Ridethrough
PwrLoss
Ridethru
L3 Stall Prevention
Stall
Prevention
L4 Reference Detection
Ref Detection
L5 Fault Restart
Fault Restart
L6 Torque Detection
To rq u e
Detection
L7 Torque Limits
To rq u e L im it
L8 Hardware Protection
Hdwe
Protection
n1 Hunting Prevention Function
Hunting Prev
n2
Speed Feedback Protection Control
AFR
n3 High-slip Braking
High Slip
n4 Speed Estimation
Observer
n5 Feed Forward
Feedfoward
Cont
o1 Monitor Select
Monitor Select
o2 Multi-function Selections
Key
Selections
o3 Copy Function
COPY
Function
T1 Motor Autotuning
Auto-Tuning
