Standard Drive Specifications
The standard Drive specifications are listed by capacity in the following tables.
Specifications by Model
Specifications are given by model in the following tables.
200-240V Class
* 1. The maximum applicable motor output is given for a standard 4-pole Yaskawa motor. When selecting the actual motor and Drive, be sure that the Drive's rated
current is applicable for the motor's rated current.
* 2. The voltage of the cooling fan for 200-240 V Class Drives of 30 kW is three-phase, 200, 208, or 220 V at 50 Hz or 200, 208, 220, or 230 V at 60 Hz.
* 3. A 3-wire transformer is required on the power supply for 12-phase rectification.
Table 9.1 200-240 V Class Drives
Model Number CIMR-G7U 20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090 2110
Max. applicable motor output
(kW)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110
Rated output capacity
(kVA)
1.2 2.3 3.0 4.6 6.9 10 13 19 25 30 37 50 61 70 85 110 140 160
Rated output current (A) 3.2 6 8 12 18 27 34 49 66 80 96 130 160 183 224 300 358 415
Max. output voltage (V)
3-phase; 200, 208, 220, 230, or 240 Vac
(Proportional to input voltage.)
Max. output frequency
(Hz)
Frequencies supported up to 400 Hz using parameter setting
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/208/220/230/240 Vac, 50/60 Hz
*2
Allowable voltage
fluctuation
+ 10%, - 15%
Allowable frequency
fluctuation
±5%
Measures for
power supply
harmonics
DClink choke Optional Built in
12-phase
rectification
Not possible
Possible
*3
Power supply characteristics
