YASKAWA G7 Series User Manual

Installing and Wiring Option Cards
2-33
 PG Speed Control Card Terminals and Specifications
The terminal specifications for the PG Speed Control Cards are given in the following tables.
PG-A2
The terminal specifications for the PG-A2 are given in the following table.
Table 2.15 PG-A2 Terminal Specifications
Terminal No. Contents Specifications
TA1
1
Power supply for pulse generator
12 Vdc (±5%), 200 mA max.
2 0 Vdc (GND for power supply)
3
+12 V/open collector switching ter-
minal
Terminal for switching between12 Vdc voltage input
and open collector input. For open collector input,
short across 3 and 4.
4
5
Pulse input terminal
H: +4 to 12 Vdc; L: +1 Vdc max. (Maximum response
frequency: 30 kHz)
6 Pulse input common
7
Pulse motor output terminal
12 Vdc (±10%), 20 mA max.
8 Pulse monitor output common
TA2 (E) Shield connection terminal -
