User Parameter Tables
5-81
Multi-function Selections: o2
User parameters for Digital Operator key functions are shown in the following table.
o1-04
Setting unit
for frequency
parameters
related to V/F
characteristics
Sets the setting units related
to V/F pattern frequency
related parameters
(E1-04, -06, -09, -11)
0: Hertz
1: RPM
0 or 1 0 No No No No A A 503H
V/f Display
Unit
o1-05
LCD
Brightness
Adjustment
Sets the contrast of the
Digital Operator LCD. A
setting of "1" is the lightest
contrast and a setting of "5"
is the darkest contrast.
0 to 5 3 YesAAAAA 504H
LCD Contrast
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
MODBUS
Register
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
o2-01
Local/
Remote Key
Function
Selection
Determines if the Digital
Operator Local/Remote key
is functional.
0: Disabled
1: Enabled
0 to 1 1 No A A A A A 505H
Local/
Remote Key
o2-02
STOP Key
Function
Selection
Determines if the STOP key
on the Digital Operator will
stop the Drive when Drive is
operating from external
terminals or serial
communication.
0: Disabled
1: Enabled
0 to 1 1 No A A A A A 506H
Oper STOP
Key
o2-03
User
Parameter
Default Value
Allows storing of parameter
settings as a User
Initialization
Selection.
0: No Change
1: Set Defaults - Saves
current parameter
settings as user
initialization. A1-03 now
allows selecting <1110> for
user initialization and
returns o2-03 to zero.
2: Clear All - Clears the
currently saved user
initialization. A1-03 no
longer allows selecting
<1110> and returns o2-03
to zero.
0 to 2 0 No A A A A A 507H
User Defaults
Parameter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Control Methods
MODBUS
Register
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vector
Open
Loop
Vector
2
