1-6
Models CIMR-G7U2018 thru 2110 and 4018 thru 4300
The external appearance and component names of the Drive are shown in Fig 1.6. The Drive with the terminal
cover removed is shown in Fig 1.7.
Fig 1.6 Drive Appearance
Fig 1.7 Terminal Arrangement
Mounting holes
Cooling fan
Nameplate
Drive cover
Front cover
Digital Operator
Terminal cover
Terminal Arrangement(18.5kW or More)
Charge indicator
Control circuit
terminals
Main circuit
terminals
Ground terminal
