YASKAWA G7 Series User Manual

6-114
 E1-04 Maximum Output Frequency
Setting Range: 0.0 to 400.0Hz
Factory Default: 60.0Hz
 E1-05 Maximum Output Voltage
Setting Range: 0.0 to 255.0V (200-240V Models)
0.0 to 510.0V (380-480V Models)
Factory Defaults: 230.0V (200-240V Models)
480.0V (380-480V Models)
 E1-06 Base Frequency
Setting Range: 0.0 to 400.0Hz
Factory Default: 60.0Hz
 E1-07 Mid Output Frequency A
Setting Range: 0.0 to 400.0Hz
Factory Default: 3.0Hz
 E1-08 Mid Output Voltage A
Setting Range: 0.0 to 255.0V (200-240V Models)
0.0 to 510.0V (380-480V Models)
Factory Defaults: 12.6V (200-240V Models)
25.2V (380-480V Models)
 E1-09 Minimum Output Frequency
Setting Range: 0.0 to 400.0Hz
Factory Default: 0.5Hz
 E1-10 Minimum Output Voltage
Setting Range: 0.0 to 255.0V (200-240V Models)
0.0 to 510.0V (380-480V Models)
Factory Defaults: 2.3V (200-240V Models)
4.6V (380-480V Models)
 E1-11 Mid Output Frequency B
Setting Range: 0.0 to 400.0Hz
Factory Default: 0.0Hz
 E1-12 Mid Output Voltage B
E1-13 Base Voltage
Setting Range: 0.0 to 255.0V (200-240V Models)
0.0 to 510.0V (380-480V Models)
Factory Defaults: 0.0V (200-240V Models)
0.0V (380-480V Models)
To set up a custom V/f pattern, program the points shown in the diagram below using parameters E1-04 through
E1-13. Be sure that the following condition is true:: E1-09 ≤ E1-07 ≤ E1-06 ≤ E1-11 ≤ E1-04
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

YASKAWA G7 Series Specifications

General

Series	G7
Frequency	50/60 Hz
Output Voltage	Matches Input Voltage
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus, DeviceNet, Profibus, Ethernet
Safety	Safe Torque Off (STO)
Operating Temperature	-10°C to 50°C
Humidity	5% to 95% (non-condensing)
Cooling Method	Fan Cooled
Enclosure Rating	IP20
Storage Temperature	-20°C to 65°C
