YASKAWA G7 Series User Manual

6-144
Storing Drive Set Values in the Digital Operator (READ)
To store Drive set values in the Digital Operator, make the settings using the following method.
An error may occur while saving to memory. If an error is displayed, press any key to cancel the error display
and return to the o3-01 display.
Table 6.1 READ Function Procedure
Step
No.
Digital Operator Display Explanation
1 Press the Menu Key, and select advanced programming mode.
2 Press the DATA/ENTER Key, and select the parameter monitor display.
3
Display o3-01 (Copy Function Selection) using the Increment Key and Decrement
Key.
4 Press the DATA/ENTER Key, and select the parameter setting display.
5 Change the set value to 1 using the Increment Key.
6 Set the changed data using the DATA/ENTER Key. The READ function will start.
7 If the READ function ends normally, End is displayed on the Digital Operator.
8 The display returns to o3-01 when a key is pressed.
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1 - 00=1
Select Language
COPY Function
-ADV-
o3 - 01=0
Copy Funtion Sel
Copy Funtion Sel
-ADV-
o3-01= 0
COPY SELECT
*0*
Copy Funtion Sel
-ADV-
o3-01= 1
*0*
READ
-ADV-
INV→OP
READING
READ
-ADV-
READ COMPLETE
Copy Funtion Sel
-ADV-
o3 - 01=0
COPY SELECT
*0*
