1 General
1.1 About this manual
This Instruction manual comprises information about:
• Installation
• Setup
The fieldbus PCI-cards are valid for YASKAWA controller NX100 and DX100 (hereafter called the
controller).
Text written in BOLD letters means command or button. Text written in ITALIC means text shown on
display.
1.1.1 Copyright
This manual may be copied for internal use without our written permission but not imparted to a third
party.
Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in
particular to trademarks, model denominations, documents, and drawings.
1.2 System requirements
1.2.1 NX100 Software
For the fieldbus PCI-card installation, the PCI card driver and version NS3.14-01A (or later) of the
NX100 system software are required.
1.2.2 DX100/DX200 software
No specific requirements.
1.3 In manual included Fieldbus PCI-cards and NetTools
Device YASKAWA Nordic
AB Part no.
Note
Profibus DP PCI-card, Slave AB3601 34790180
Profibus DP PCI-card, Master AB3602 34790190
DeviceNet PCI-card, Adapter(Slave) AB3603 34790080
DeviceNet PCI-card, Scanner(Master) AB3604 34790090
AS-Interface(ASI) PCI-card, Master AB3605 34790290
EtherNet/IP PCI-card, Slave/Adapter AB3606 34790380
EtherNet/IP PCI-card, Master/Scanner AB3607 34790390
PROFINET-IP PCI-card, Slave AB3609 34790480
FL-Net PCI-card, Slave AB3610 34790580
FIPIO PCI-card, Slave AB3611 34790680
Interbus-S PCI-card, Slave AB3615 34790780
CanOpen PCI-card, Slave AB3616 34790880
Reg.No. ME00107EN-02 Page 7
