YASKAWA NX100 - Network Setup

Fieldbus PCI-Card
Network setup
Pin RJ45
(Female) Signal
1 TD+
2 TD-
3 RD+
4 Termination
5 Termination
6 RD-
7 Termination
8 Termination
12.3 Network setup
Two unique IDs have to be set on the ProfiNet slave:
• IP address
• Device Name
Set a Device Name for the module when the Anybus PROFINET IO module is to be used for the first
time in the network. The Device Name must be unique within the network. The IP address can be
assigned by the master, by DHCP, or set explicitly .
Both the IP address and the device name can be set by, e.g. Siemens engineering tool. There is a
guide for the Siemens tool on the HMS webpage. If using more than one AB3609 they can be
distinguished by their MAC addresses.
The IP address on the board is set with the HMS “Anybus IPconfig” tool which can be downloaded
from the HMS support webpage.
See section 4 General installation in IP-based networks.
The configuration of AB3609 can be read by accessing the modules built in FTP server. The settings
are in the files “ethcfg.cfg” and “pniocfg.cfg”.
Page 60 Reg.No. ME00107EN-02
