14 FIPIO Slave AB3611
14.1 FIPIO Interface Details
General features:
• Supports both FIP and WorldFIP standards
• Baudrate. The baud rate is fixed to the standard FIPIO baudrate 1Mbit/s
• The FIPIO slave is configured as a Class 0 device, i.e. it cannot change configuration in run-time.
It supports all 3 different FIPIO profiles:
• FRD C2 = FRDP - FIPIO Reduced Device Profile. Up to 2 words in/out = 4 bytes = 32 bits.
• FSD C8 = FSDP - FIPIO Standard Device Profile. Up to 8 words in/out = 16 bytes = 128 bits
• FED C32 = FEDP - FIPIO Extended Device Profile. Up to 32 words in/out = 64 bytes = 512 bits.
• The profile is selected depending on the configured IO size.
14.2 Card
Caution
The card contains ESD sensitive components. Observe ESD precautions when handling the
card.
Fig. 54 FIPIO slave card
The top connectors are most bus IN interface. The bottom connectors, above the LEDs are bus OUT
interface.
Reg.No. ME00107EN-02 Page 63
