Fieldbus PCI-Card
General
2 Installation
2.1 General
2.1.1 Specification
3.3 and 5 V support (Universal keyed add-in)
Competitively priced - high performance
Easy plug-and-play interface
2.1.2 Technical specification
Size(W x L x D): 100 x 120 22 mm (3.94” x 4.72” x 0.87”)
Power supply: 3.3 and 5 V, 600 mA VDC
Temperature: operating +55°C
2.1.3 Compliances and conformances
EMC compliance: 2004/108/EC
a. Emission: EN 61000-6-4:2001
b. Immunity: EN 61000-6-2:2001
CE marked
UL conformance
Tested and verified for Fieldbus and network conformance
RoHS compliance
2.2 Hardware installation
Warning
To prevent electrical shock to personnel and to prevent equipment damage, ensure
power to the robot control system is turned OFF before beginning the installation.
Caution
Never change any of the settings on the PCI-card while controller power is ON.
Caution
The card contains ESD sensitive components. Observe ESD precautions when handling the
card.
The following installation instructions apply to all fieldbus PCI-cards delivered by YASKAWA.
Reg.No. ME00107EN-02 Page 11
