General
17 EtherCAT slave AB3617
17.1 General
EtherCAT slave is supported by the system sw and the HMSAB.DRV version 1.6.5.9.
17.1.1 Interface details
• CANopen over EtherCAT
• DS301 v4.02 compliant
• Galvanically isolated network electronics
• Generic Device Description File provided
17.2 Card
Caution
The card contains ESD sensitive components. Observe ESD precautions when handling the
card.
Status LEDs
EtherCA T in-port
EtherCA T out-port
Fig. 70 EtherCAT slave card
